2023 GASGAS MC-E 5

£5,370
£4,950
Enquire now

Interested in this bike? Call us 01539 732666

Bike Year
2023
Bike Model
MC-E 5
CC
50
Colour
RED

Creating some serious buzz over the last couple of years, it's safe to say that our MC-E 5 has been a monumental hit! The ideal dirt bike for youngsters to learn on,it offers an adjustable seat height and six different ride modes for safe, controlled progression. Offering up to two hours of uninterupted riding time, it'll then need just one hour to fully recharge. How cool is that? With its lithium ion battery housed in a lightweight yet strong chassis, this mini racer is complete with WP Suspension and constructed with quality components, just like it's bigger brothers.

Specifications

Chassis
FRONT BRAKE DISC DIAMETER
160 mm
REAR BRAKE DISC DIAMETER
160 mm
FRONT BRAKE
Disc brake
REAR BRAKE
Disc brake
CHAIN
1/2 x 3/16"
FRAME DESIGN
Central-tube frame with double-cradle
FRONT SUSPENSION
XACT 35 WP Upside-Down fork, Ø 35 mm
REAR SUSPENSION
XACT WP mono shock
STEERING HEAD ANGLE
66 °
SUSPENSION TRAVEL (FRONT)
205 mm
SUSPENSION TRAVEL (REAR)
185 mm
Engine
RATED OUTPUT
2 kW / 3,200 rpm
TORQUE
13.8 Nm
TRACTION BATTERY
Lithium-Ion KTM PowerPack
BATTERY CAPACITY
21 Ah
RATED VOLTAGE
48 V
CHARGER LINE VOLTAGE
80-240 V/50-60 Hz
CHARGING INPUT
Quick charging 5 A @ 230 V (AC)
CHARGING POWER
900 W
CHARGING TIME 100%
70 min.
CHARGING TIME 80%
45 min.
COOLING
Air cooled
ELECTRIC MOTOR
48 V - BLDC motor with outer rotor - 6000 rpm
MAX POWER
5 kW / 3,900 rpm
Further Information


MC-E 5

Creating some serious buzz over the last couple of years, it's safe to say that our MC-E 5 has been a monumental hit! The ideal dirt bike for youngsters to learn on,it offers an adjustable seat height and six different ride modes for safe, controlled progression. Offering up to two hours of uninterupted riding time, it'll then need just one hour to fully recharge. How cool is that? With its lithium ion battery housed in a lightweight yet strong chassis, this mini racer is complete with WP Suspension and constructed with quality components, just like it's bigger brothers.

STYLE

BODYWORK

The flat seat profile on the MC-E 5 encourages youngsters to quickly learn the fundamentals of sitting and standing correctly with the sleek bodywork allowing for completely unrestricted movement on the bike. With a cool, all-red look, obviously!

GRAPHICS

It’s got to look good, right? Just like every other GASGAS motocross bike the MC-E 5 has a striking look, modern graphics and lots of red, our favorite color! There’s also a splash of blue, to signify its electric drive. All graphics are applied using an in-mold process to ensure long lasting good look.

HANDLEBARS

Youngsters need to feel confident, in control. That’s exactly why we’ve fitted tapered NEKEN handlebars to our MC-E 5. Fitted with smaller diameter grips, junior riders can get a good grasp of their new pride and joy, increasing their control and reducing tiredness. An innovative throttle assembly designed especially for electric drive is fitted with a vulcanized ODI grip while a non-glue lock-on grip is fitted to the left side of the handlebars.

HANDLING

FRAME

Wrapped around the 5kW motor is a super tough chromoly steel frame. Giving youngsters all-important stability, ease of handling and precise cornering, our engineers have designed each frame to deliver just the right amount of flex and stiffness.

WP FORKS

With 205mm of travel the lightweight WP XACT forks deliver seriously impressive, and progressive, front-end damping performance. The 35mm USD forks feature the latest internal tech, allowing youngsters to focus on riding and having fun. Fully adjustable with just a hand pump, the air unit in the left fork leg can be adjusted to suit rider preference, weight and, when they start racing, track conditions.

WP SHOCK

Quality parts run throughout the MC-E 5, like the WP monoshock, which is linked directly to the swingarm. Set-up to be perfectly matched to the WP XACT forks, the fully adjustable shock offers a massive 185mm of suspension travel to deliver precise rear-end damping.

SEAT HEIGHT

Being able to put both feet on the floor is essential for young riders and racers. The MC-E 5 has a variable seat height, which can be adjusted from 665mm to 616mm. Quick and easy to do by lowering the seat/bodywork, alternatively, further adjustment can be achieved by mounting the rear shock in a different position and lowering the front forks. To accommodate riders as young as 4, the suspension units can be lowered further with a Suspension Lowering Kit, available from the Accessories catalogue.

MOTOR

ELECTRIC MOTOR

Smooth and powerful, the 5kW motor is super compact and the perfect fit for our smaller chassis. Air-cooled, dust and water resistant it’s also wear and maintenance-free. The integrated control unit (ECU) guarantees a direct, but very controllable power delivery.

CONTROL CENTER

Some call it a multi-functional instrument, we call it the control center – the little box of lights and magic that’s placed in front of the seat, close to the steering head. Offering riders and parents a choice of 6 different ride modes, power settings can be selected to suit pure beginners or more experienced racers. The control center also displays the remaining battery power.

BATTERY

Our lithium ion battery does two things – powers the MC-E 5 and keeps youngsters smiling like every day is Christmas! A total of 84 modern lithium ion cells are housed within our robust die-cast battery case, which is mounted above the motor. The 907Wh of stored energy is good for two hours of riding for a beginner or 25 minutes for riders that rip. The integrated battery management system (BMS) ensures the safety and longevity of the battery pack.

CHARGER

Quick. Simple. Clean. Needing just 60 minutes for a full charge or 45 minutes for an 80 percent charge, the MC-E 5 comes with a 110-230 volt worldwide charger, which plugs straight into the battery pack for easy charging

PARTS

SAFETY

Riders make mistakes, it’s all part of the fun! But it also has to be safe, which is why the GASGAS MC-E 5 is fitted with a roll-over sensor that cuts off the power if a rider crashes or falls. With a lanyard attached to both their wrist and the bike, in the event of a rider falling the motor is stopped. Adjustable ride modes can also be set and saved with a dongle, preventing excitable racers from changing to more powerful riding mode before they’re ready for them!

BRAKES

To slow youngsters down and to stop mum from worrying, the MC-E 5 has serious stopping power. Fitted with hydraulically operated brake calipers matched to waved front and rear brake discs, the system ensures powerful brake performance in all conditions.

WHEELS

Just like our full-size motocross bikes, the wheels fitted to the MC-E 5 guarantee strength and reliability. Featuring super cool, lightweight black anodized aluminum rims, MAXXIS tires provide the grip, no matter the riding surface.
